Infrared IWB is used for education, conference, presentation and other applications. It is easy to use and multi-functional, it achieves the interactive purpose between user and machine, give students a vivid sensory experience with music, sounds, images, and animation, motivate students to participate and inspiring teachers too.
Interactive whiteboards are a key component to 21st century all-in-one classroom solution, We haves a wide range sizes ( 72”, 86”, 102”, 116” ) to meet your diverse requirements, our custom department will happy to hear from customers’ designs and work closely to turn their ideas into reality.
|
|
|
Tecnologia de toque
|
Toque Infravermelho
|
|
Writing
|
Pen, fingers, teaching pointer or any other opaque object
|
|
Communication
|
USB
|
|
Elétrico
|
Resolução
|
16384×16384
|
|
Average orientation precision
|
≤0.1mm
|
|
Maximum position deviation
|
≤1mm
|
|
Objeto de toque mínimo
|
5mm
|
|
Taxa de processo
|
500 points/second
|
|
Anti-light intensity
|
Can be used in the direct sunlight
|
|
cursor speed
|
180 points/second
|
|
Potência
|
Power by USB cable, Power Consumption＜1W
|
|
Shortcut keys
|
16 shortcut keys on the each side of the board
|
|
Support system
|
XP, Vista, Win7,Linux, Mac OS X 10.5 above
|
|
Driver de Hardware
|
|
|
Gesture recognition
|
Write with single touch, move current page to anywhere with two point touch, page up and page down, rotate with two point touch, zoom in and zoom out, palm can be recognized as eraser
|
|
Installation
|
Mounted on wall、steel guide ways or floor Stand
|
|
Specification
|
IR-8072
|
IR-8086
|
IR -8102
|
IR -8116
|
|
Dimensions（cm）
（L×A×P）
|
144×111×4
（72 polegadas）
|
176×128×4
（86 polegadas）
|
225×128×4
（102 polegadas）
|
257×144×4
（116 polegadas）
|
|
Effective writing area（cm）
|
130.4×97.8
（64 polegadas）
|
162.7×114.7
（78 polegadas）
|
211.9×114.7
（95 polegadas）
|
243.5×131
（109 polegadas）
|
|
Net weight（kg）
|
18
|
24
|
31
|
38
|
|
Package size（cm）
|
154×120×11
|
186×136×11
|
234×136×11
|
266×153×11
|
|
Package weight（kg）
|
22
|
29
|
36
|
43
|
|
|
cabo USB
|
One 5m cabo USB
|
|
Caneta de quadro branco
|
two
|
|
Floor stand
|
opcional
|
|
Suporte de foco curto
|
opcional
|
|
Shipping size of floor stand（mm）
（L× H× D）
|
1730×740×90
|
|
Shipping weight of floor stand
（kg）
|
27
|
|
Projection proportion
|
4:3
|
16:9
|
|
Temperatura (Workable)
|
0-40℃
|
|
Humidity(Workable)
|
20-90%
|
|
Storage Temp
|
-40-50℃
|
|
Umidade de armazenamento
|
10-95%
|
|
Garantia
|
5-year limited equipment warranty upon registration
|
|
Nota
|
Erro de tamanho: ±3mm,Erro de peso: ±1Kg.The shape and standard are subject to change without notice
|
|
